Angleadjustment
ii.L oosenthe2mountingbracketscrewstoadjustthetransducerheight.
5.R e-tightenthemountingboltandmountingscrewsbeforere-testing.
7.7Finalizingthetransducermounting
Aftermakinganynecessaryadjustmentstoachieveoptimumperformance
foryourvessel,thetransducerinstallationmustbefinalizedbylockingthe
transducer’sposition.
Note:
A
fteryouapplymarinegradesealant,alwaysallowtimeforthesealantto
fullycurebeforereturningyourvesseltothewater.
1.Drilltheholeforthefinallockingscrew,takingcarenottodamagethe
mountingbracket.
2.Applymarinegradesealanttothescrewthread.
3.Insertandtightenthethird‘locking’screw.
4.Carefullyremovethe2xscrewsintheadjustmentslots.
5.Applymarinegradesealanttothescrewthreads.
6.Re-insertandtightenthescrews.
Installation31
