RT-7600S Auto Hematology Analyzer User’s Manual
42
Select appropriate unit, and click “OK” to save and exit, click “Cancel”, the Units will not be
changed.
7.2.5 Communication
Communication setting is used to set up each parameter value for serial port transfer
interface, to check or modify these settings, click “Communication” button, open
communication setting menu as follows:
Fig.7-8 Communication setting
Instrument default values are: Baud rate: 115200, data digit: 8, calibration digit: None, stop
digit: 1. to modify setting, click dropdown box, select other different value, click “OK” button.
7.2.6 Department information
Department information is used to set up department data of user unit, user message setting
and sample data entry will use department message, preset these messages will speed up
department data input. Click “Dept. Info” button, open department message menu as follows:
Fig.7-9 Department message setting
