AppendixII List of product tubes
Tube
ID（mm）
(mm)
OD(mm)
(mm)
Length(mm)
(mm)
Description
Tube76- 1
1.30
3.00
380
Connect the sampling needle and piston 3.
Tube 76-2
1.52
3.22
40
Connect the temperature sensor and piston 1.
Tube 76-3
1.52
3.22
400
Connect the tube connector and valve SV1.
Tube 76-4
1.52
3.22
100
Connect the piston 2 and valve SV1.
Tube 76-5
1.52
3.22
400
Connect the sampling needle and valve SV6.
Tube 76-6
1.52
3.22
140
Connect the valve SV8 and piston 3.
Tube 76-7
1.52
3.22
400
Connect the sampling needle and valve SV7.
Tube 76-8
1.52
3.22
60
Connect the valve SV7 and valve SV8.
Tube 76-9
1.52
3.22
220
Connect the SV9 and temperature sensor.
Tube 76-10
1.52
3.22
60
Connect the valve SV9 and SV8.
Tube 76-11
1.52
3.22
70
Connect the RBC buffer cell and RBC counting
cell.
Tube 76-12
1.52
3.22
200
Connect the RBC and WBC counting cell.
Tube 76-13
1.52
3.22
40
Connect the WBC counting cell and 3-way
connector 1.
Tube 76-14
1.52
3.22
50
Connect the WBC counting cell and 3-way
connector 2.
Tube 76-15
1.52
3.22
80
Connect the WBC buffer cell and 3-way
connector 1.
Tube 76-16
1.52
3.22
20
Connect the 3-way connector 1 and the tube
connector.
Tube 76-17
1.52
3.22
150
Connect the 3-way connector 2 and valve SV7.
Tube 76-18
1.52
3.22
400
Connect the 3-way connector 2 and valve SV3.
Tube 76-19
1.52
3.22
270
Connect the valve SV6 and negative pressure
syringe.
Tube 76-20
1.52
3.22
60
Connect the valve SV4 and negative pressure
syringe.
Tube 76-21
1.52
3.22
400
Connect the RBC counting cell and valve SV4.
Tube 76-22
2.06
3.76
800
Connect the MTLL220-1and Diluent bottle.
Tube 76-23
2.06
3.76
450
Connect the MTLL220-3 and Lyse.
Tube 76-24
2.06
3.76
42
Connect the valve SV11 and 3-way connector 4.
Tube 76-25
2.06
3.76
40
Connect the 3-way connector 4 and 3-way
connector 3.
Tube 76-26
2.06
3.76
400
Connect the valve SV1 and FTLB220-1。
Tube 76-27
2.06
3.76
400
Connect the valve SV9 and FTLB220-1。
Tube 76-28
2.06
3.76
20
Connect the valve SV10 3-way connector 4
Tube 76-29
2.29
3.99
230
Connect the valve SV5 and FTLB220-1。
Tube 76-30
2.29
3.99
60
Connect the valve SV2 and negative pressure
syringe.
Tube 76-31
2.29
3.99
140
Connect the 3-way connector 3 and negative
pressure syringe.
Tube 76-32
2.29
3.99
800
Connect the MTLL220-4 and wash bottle.
Tube 76-33
2.29
3.99
190
Single tube, connect the valve SV2.
Tube 76-34
2.29
3.99
280
Single tube inside the Diluent bottle.
Tube 76-35
2.29
3.99
190
Single tube inside the wash bottle.
Tube 76-36
2.29
3.99
180
Connect the WBC buffer cell and valve SV11.
Tube 76-37
2.29
3.99
150
Connect the RBC buffer cell and valve SV11.
Tube 76-38
2.29
3.99
60
Connect the 3-way connector 3 and valve SV5.
Tube 76-39
2.29
3.99
190
Single tube inside the Lyse bottle.
Tube 76-40
2.29
3.99
320
Connect the valve SV3 and FTLB220-1。
Tube 76-41
3.0
6.0
1500
Connect the MTLL013-5 and waste bottle.
Notice: The number of tube can be seen in the machine
