LIFTLOG 1000 – INSTALLATION AND CALIBRATION
11
1.6 Hydraulic Fitting Kits (options)
Pressure Circuit (Cylinder Return circuit – Feed to Drop Valve)
The correct tee fitting kit should have been specified and supplied for the particular machine. Unless otherwise specified, the
system is supplied with kit K/VHL/INST/005 to drill and tap a 1/8” BSP port at a suitable point in the lift cylinder return circuit.
Return to Tank Circuit
In addition to the standard ½” Hose kit supplied, the correct tee fitting kit should have been specified and supplied for the
particular machine, to tee this hose into the hose returning to the hydraulic tank. Unless otherwise specified, the system is
supplied with kit K/VHL/INST/056 to suit a ½” bore tank return.
The optional LP tee kits are:
1-1/4” Low Pressure Hose Kit
1-1/2” Low Pressure Hose Kit
NOTE: Low pressure Hose kits are rated to 25 bar.
