LIFTLOG 1000 – INSTALLATION AND CALIBRATION
34
“Secure >0< Key” If enabled, PIN entry is required to access the zero routine on the main operating screen (the PIN is the
current factory level PIN as displayed on the “PIN” screen).
“Enable Nudge” Enable the Nudge function.
“Auto Add Delay” The time after weight sampling before the weight is automatically added to the weight total.
Press to exit the “Sensor Setup” screen.
3.4.5 Overload Alarm Setup
“Enabled” The overload function may be disabled if desired, in which case
the “load bar” will not be displayed on the main operating
screen.
“Max Capacity” The weight at which overload occurs. Either,
(i) Select "Max Capacity" and then press to manually program
in the weight units (kg, lbs), or,
(ii) Do an "Autocal". Load the forks to the maximum that is still safe to
lift, (keeping the forks low to the ground in case the machine
overbalances). Press and then to set the overload
threshold.
"Overload Zero" The overload zero point (% pressure with empty forks) saved from
the Auto Weight calibration routine (3.4.1).
NOTE: The Overload Alarm function is not a safety device!
