LIFTLOG 1000 – INSTALLATION AND CALIBRATION
9
1.5 Hydraulic Fitting Kits (standard unless otherwise specified)
Unless specified otherwise, the following kits are supplied as standard with the main kit (ref. fig.1 overleaf)
Item
Part No.
Description
Qty
Pressure Circuit (Cylinder Return circuit – Feed to Drop Valve)
K/VHL/INST/053
3/8” BSP High Pressure Hose Kit
1
1
S/HY/500-9-099
3/8” BSPF – 3/8”BSPF Hose, 250bar, 1M
1
2
S/HY/500-9-100
¼” BSPF – 3/8” BSPM Adaptor
1
3
S/HY/500-9-101
3/8”BSPM – 3/8” BSPM Adaptor
1
4
S/HY/500-9-102
3/8” BSP “Dowty” Seal
1
5
S/FSNR/940221
¼” BSP “Dowty” Seal
1
#
K/VHL/INST/005
Tapped Port Kit (ref section 1.6 for alternatives)
1
Return to Tank Circuit
K/ VHL/INST/055
½” Low Pressure Hose Kit
1
6 #
S/HY/500-9-103
½” Hose, 25 bar, 2.5M
1
7
S/HY/500-9-101
3/8”BSPM – 3/8” BSPM Adaptor
1
8
S/HY/500-9-102
3/8” BSP “Dowty” Seal
1
9
S/HY/500-9-104
3/8” BSPM – 3/8” BSPF Elbow
1
10
S/HY/500-9-105
½” BSPF Hosetail
1
11
S/FIXING/084
13 – 20mm Hose Clip
4
K/ VHL/INST/056
1/2” Low Pressure Tee Kit (ref section 1.6 for alternatives)
1
12
S/HY/500-9-106
½” BSPM Hosetail
3
13
S/HY/500-9-107
3/8” BSPF Equal Tee
1
# Not illustrated.
