LIFTLOG 1000 – INSTALLATION AND CALIBRATION
33
“Correct from Weight” - “Wf” on graph.
“Correct to Weight” - “Wt” on graph.
The range over which the correction factor is applied.
“% Correction” - Correction applied between 'Wf' and 'Wt' on
graph.
3.4.4 Sensor Setup
Press to edit settings requiring a numeric entry.
“Reference Sensor” If fitted, the reference sensor only enables the weigh
button to operate at the weighing position.
“Drop Sample Time” The time after pressing the weigh button and the
“Sample Start Delay”, during which the weight is
sampled and averaged.
“Sample Start Delay” The time after pressing the weigh button, before the
solenoid activates and weight sampling commences.
This allows the hydraulic pressure to stabilize prior to
the sampling period and improves accuracy.
“Overload Log Delay” The time that the pressure is detected to be constantly over the “Overload Level” before logging an
overload event.
“Overload Smoothing” This helps to prevent unnecessary overload events being logged due to inadvertent pressure transients,
caused for example by sudden lifting or other movement.
