REA MLV-2D User Manual

REA VERIFIER
© REA Elektronik GmbH, 64367 Mühltal, Germany --- REA MLV-2D Manual Version 3 – 21/12/2015 Page 96 of 98
21 Technical data
Barcode and matrix code verifier
Mains charger power sup
ply
Via Power
-
over
-
Ethernet (PoE)
power adapter, supplied. Prim.
110–240 V AC, 0.4 A, sec. 48 V DC,
0.32 A
Housing
Terminal, body and legs, base
plate: aluminium, powder-coated,
black
Display
TFT colour graphics display, 320 x
240 pixels, 16-bit
Camera
and field of view
Replaceable camera module,
resolution 1,280 x 1,024, see
section 2.2
Lighting, standard angle
Quadrilateral red light 45°,
quadrilateral red light 10°,
quadrilateral white light 45°,
quadrilateral white light
Lighting, light type
Red: wavelength 660 nm, white:
light temperature 4400 K
Lighting, optional
90° coaxial lighting with 4000 K
white light, DOM lighting in
preparation
Aperture
The camera aperture is
preconfigured and must not be
modified
Measuremen
t aperture
The synthetic aperture is an image
filter that adopts specific sizes
according to a standard or a user
requirement (between 3 mil (0.075
mm) and approx. 20 mil (0.5 mm))
(see section 10.6)
Focus
Preconfigured to the
measurement
level The focal position must not be
modified.
Keyboard
Membrane keyboard with 21 short
-
travel keys
Terminal processor
Processor
ARM 9®
microprocessor, 32-bit, at 180 MHz
Memory/RAM
16 MB flash ROM,
32 MB RAM,
internally expandable with MMC
flash card
Operating system
Embedded Linux for ARM
processors
Evaluation software
Verifier Device Server as PC
-
based
device service
