Page 30 of 55 12/2006 Rev. B Manual DFA 127 Full Power
Configuration
Configurations of the DFA 127 can only be made with the electronic BDE-D or the
optional Testbox. If a toggle switch is connected, a BDE-D or Testbox must be con-
nected briefly for the configuration.
Please always leave the configuration review sheet in the drive even when the STG
is replaced!
15.2 Parameter Description
Parameter Setting
range
Factory
default
Description
DRIVING CYCLE
Closing speed 0 - 40
(5 – 20 s)
18 Slider control with 40 steps
Opening speed 0 - 40
(3 - 20 s)
36 Slider control with 40 steps
Acceleration 0 – 40
(40 = max.)
36 Influences the start-up behaviour
while opening and closing
Latch check 0 – 40 0 Earlier slow-down while closing elon-
gates the length of run with minimal
possible closing speed in the area of
the last 20° (e.g. safeguarding
against shearing edge)
TIME DELAY OPEN
Time delay open 0 – 40
(0 – 60 s)
2 Effective with AKA, AKI and push to
actuate
0 – 20: Steps of 1 s
21 – 40: Steps of 2 s
Time delay SSK 0 – 40
(0 – 60 s)
4 Effective with SSK
0 – 20: Steps of 1 s
21 – 40: Steps of 2 s
DRIVE
Opening angle 0 – 40 35 The opening angle is estimated dur-
ing the calibration run and is equiva-
lent to the value of 40
Collision 0 – 40 20 Influences the force for the reversing
0: weak
40: strong
Without No brake integrated or no brake
wanted
Closing
position
Holding brake with closed door
Opening
position
Holding brake with open door
Brake
Open/clos
ed position
Without
Holding brake with open and closed
door
