Manual DFA 127 Full Power 12/2006 Rev. B Page 35 of 55
Configuration
Parameter Setting
range
Factory
default
Description
LOCKING
Normally
locked
The VRR interlock is operated with
the Lock button on the BDE-D or via
the Lock position of the switch on the
BDE-M.
Locking function
Always
locked
Normally
locked
The interlock VRR is permanently
active and unlocks before opening
with each connected actuator.
Standard For the standard electronic lock (e.g.
eff-eff). The operator holds the door
closed until the lock is unlocked. It
remains actuated until the door is
fully opened.
Suitable for motor-lock. The operator
holds the door closed until the lock is
unlocked. The power remains on
until the door is closed again.
Locking
bolt
The VAK input waits a max. of
indication of the reverse signal input
of the lock before the door opens.
Magnet Analogous to bolt-function, but with-
out holding closed.
Lock type
Pulse
Standard
The operator holds the door closed
until the lock is unlocked. It remains
actuated until the door is approx. 10°
opened.
Disabled VRR manually
Enabled
Disabled Enabled: All the actuators are dis-
connected if a signal is present on
the VAK input from the reverse sig-
nal input of the lock .
Approved for doors that are closed
manually.
Start delay 0 - 40
(0 - 8 s)
0 Application for motor locks without
reverse signal on the input VAK. The
opening is time-delayed.
INPUT
Disabled AUX1_IN
BEA
Bodyguard
