Page 34 of 55 12/2006 Rev. B Manual DFA 127 Full Power
Configuration
Parameter Setting
range
Factory
default
Description
CONTROL PAN-
EL
3-digit
(AUTO)
Manual; Automatic; Cont. open
Function corresponds to the symbols
on the three-step rocker switch BDI
on the side cover of the DFA 127.
4-digit
Automatic; Manual; Con. open; Locked
Adequate setting for time switch en-
tries (e.g. SUR-V).
Only possible with optional BDI-M.
3-digit *
(OFF-A)
Automatic; OFF; Cont. open
3-digit *
(OFF-M)
Manual; OFF; Cont. open
3-digit *
(LOCK-A)
Automatic; Locked; Cont. open
3-digit *
(LOCK-M)
Manual; Locked; Cont. open
Mechanical panel
(BDE-M)
1)
3-digit
(AUTO)
* CAUTION: Function does not cor-
respond to the symbols on the three-
step rocker switch BDI on the side
cover of the DFA 127.
BDE-D
(à Submenu)
Deutsch
Français
English
Language
English US
English Language for the text output
Normal Standard-Function (not for the USA) Keyboard
OFF-
Mode
Normal
Special mode according to the de-
scription in chapter 13.2. The Locked
mode is replaced by OFF.
Contrast BDE 1 0 - 40 0 Contrast setting for the BDE 1 dis-
play.
Contrast BDE 2 0 - 40 0 Contrast setting for the BDE 2 dis-
play.
Light time 0 - 40 0 Length of time for backlight:
0: No backlight
1 - 39: Corresponds to 1 - 39 s after
pushing a key on the BDE-D
40: Continuous backlight
Changes to the setting of the BDE-D
are only effective after a restart.
