Manual DFA 127 Full Power 12/2006 Rev. B Page 33 of 55
Configuration
Parameter Setting
range
Factory
default
Description
MANUAL CON-
TROL
Disabled During closing
Enabled
Disabled Enabled: The door closes motor-
guided only with spring tension.
Disabled When locked
Enabled
Disabled Enabled: When the door is in the
Locked operation mode, it can be
opened manually. The closing does
not take place automatically. (night
watchman mode).
Disabled When automatic
Enabled
Disabled Enabled: When the door is in the
Automatic operation mode, it can be
opened manually. The closing does
not take place automatically.
Disabled Collision
Enabled
Disabled Enabled: If the door leaf during clos-
ing stands still longer than 1 s, it is
reopened with motor force. Active
only, if a motor forced opening is
allowed, e.g. Manual contro/Active
Sensors.
Disabled
Constant
Constant: constant motor closing
force during the last 10°.
Cumula-
tive
Increasing motor closing force if the
closing is obstructed during the last
10°.
Final bang
Excursive increasing motor closing
force during the last 2°.
Slowly,
cumula-
tive
Slow closing with increasing motor
closing force, if the closing is ob-
structed during the last 10°.
Support during
closing
Slowly,
final bang
Disabled
Decelerated closing with excursive
increasing motor closing force during
the last 2°.
Disabled No sensor active
SIS dis-
abled
All sensors active (without SIS)
Active sensors
SIS en-
abled
Disabled
All sensors active (including SIS)
Closing speed 0 - 40 20 Slide control with 40 steps, setting
the closing speed as it sees fit. Pre-
sent locks must lock in place. This
depends on the adjusted spring
force.
