Page 32 of 55 12/2006 Rev. B Manual DFA 127 Full Power
Configuration
Parameter Setting
range
Factory
default
Description
MASTER/SLAVE
2 DOOR LEAVES
Master +
Slave
AKA is effective on both operators Function AKA
Master
only
Master +
Slave
Entry AKA is only effective on the
Master operator, AKI and SSK are
effective on both operators. One-way
mode not possible.
Overlap 0 - 40 5 Only one door leaf moves in the pre-
set overlap region.
During the opening, the stationary
leaf waits until the moving leaf has
left the overlap region y.
During closing, the moving leaf waits
until the stationary leaf has closed.
Open sequence 0 - 40 5 Delayed start-up of the stationary
leaf
Delayed closing of the moving leaf Close sequence 0 - 40 20
All modulators at 0 = synchronous
activity.
Opening or closing sequence on 40:
The subsequent door leaf waits until
the first leaf has entirely opened or
closed. With this setting, the overlap
has the highest priority.
