Red Jacket CoreDEF Series - Page 26

Installation Wiring Diagrams
22
Figure 22. Isotrol To Remote Control Box With 120 Vac Coil And Capacitor (Models 880-045-5 Or 410861-001)
NEUTRAL
DISPENSER INPUTS
HOT
TB2
TB1
ATG S NL1L2M2M1
123 45678
CHANNEL 1
CHANNEL 2
CHANNEL 3
CHANNEL 4
CHANNEL 5
CHANNEL 6
CHANNEL 7
CHANNEL 8
PHASE ON L1 MUST BE SAME AS DEVICE
CONNECTED TO ATG TERMINAL
L1
UNSWITCHED NEUTRAL
UNSWITCHED
NEUTRAL TO TB2
ISOTROL CONTROL BOX (P/N 880-049-1)
120 VOLT
DISPENSER
SIGNALS
120 VOLTS FROM
SUPPLY PANEL
120 VOLT ISOLATED OUTPUT
TO CONTROL BOX OR ATG
NOT
USED
NOT
USED
NOT
USED
NOT
USED
115 volt
25 watt
max.
Load center
208 or 230 volt
L2 L1
N
3 P.S.T. toggle
switch
Pilot light
Line starter
Capacitor
P
EXT
PILOT
LIGHT
S1 S2 S3 M3 NM1 M2 L1 L2
UMP
BLACK
BROWN
GREEN/YELLOW
GREY
DISCONNECT, LOCK OUT,
AND TAG POWER AT THE
POWER PANEL BEFORE
WIRING THE PUMP.
WARNING
OFF
Make ground connection in
accordance with local codes.
NOTICE
Make ground connection in
accordance with local codes.
NOTICE
Connect To
Electrical Ground
Connect To
Electrical Ground
