RED DSMC User Manual

RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC
955-0020_V5.1, REV-H | 149
SCARLET-X DRAGON
SCARLET-X DRAGON TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Sensor 19 MEGAPIXEL RED DRAGON
™
Pixel Array 6144 (h) x 3160 (v)
S/N Ratio 80 dB
Dynamic Range 16.5+ stops
Max Image Area 6144 (h) x 3160 (v)
Lens Coverage 30.7mm (h) x 15.8mm (v) x 34.5 mm (d)
Lens Mount DSMC TI PL Mount
DSMC TI Canon Mount
DSMC AL Canon Mount
DSMC AL Leica M Mount
DSMC AL Nikon Mount
DSMC TI Nikon Mount
DSMC RED MOTION MOUNT
TM
TI PL
DSMC RED MOTION MOUNT
TM
TI CANON
(all lens mounts sold separately)
Max Depth of Field Equivalent to S35mm (Motion)/APS-H (Still) lenses
Acquisition Formats 6K RAW (Full Frame)
5K RAW (Full Frame, 2:1, 2.4:1, 16:9)
4K RAW (Full Frame, 2:1, 2.4:1, 16:9)
3K RAW (Full Frame, 2:1, 2.4:1, 16:9)
2K RAW (Full Frame, 2:1, 2.4:1, 16:9)
Project Frame Rates 23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94 FPS, all resolutions
Delivery Formats 4K: DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
2K: DPX, TIFF, OpenEXR (.RED via RRencode Plugin)
1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG
Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
Program Output HD-SDI Clean Feed
2K RGB, 1080p RGB or 4:2:2, 720p 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Monitor Output HD-SDI and HDMI with Frame Guides and Lookaround
2K RGB, 1080p RGB or 4:2:2, 720p RGB or 4:2:2
SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
Digital Media REDMAG 1.8" SSD: 48GB, 64GB, 128GB, 240GB, 256GB, 512GB
RED MINI-MAG: 512GB
