COPYRIGHT © 2014 RED.COM, INC
RED DSMC OPERATION GUIDE
955-0020_V5.1, REV-H | 150
SCARLET-X DRAGON TECHNICAL SPECIFICATIONS
SPECIFICATION DESCRIPTION
Maximum Frames
Per Second (FPS)
6K FF: 12 FPS (in Burst mode)
5K FF: 48 FPS
4K FF: 60 FPS
3K FF: 80 FPS
2K FF: 120 FPS
5K 2.4:1: 60 FPS
4K 2.4:1: 75 FPS
3K 2.4:1: 100 FPS
2K 2.4:1: 150 FPS
Audio 2 channel, uncompressed, 24 bit, 48KHz.
Optional 4 channel, and AES/EBU digital audio.
Monitoring Options RED TOUCH 5.0" LCD
RED PRO 7" LCD
RED TOUCH 9.0" LCD
BOMB EVF (LCOS)
RED BOMB EVF (OLED)
Remote Control REDLINK Wireless, Ethernet, RS232, GPI Trigger
Weight 5lbs. Body only
Construction Aluminum Alloy
Operating Temperature
Range 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature
Range -20˚C to 50˚C (-4˚F to 122˚F)
