COPYRIGHT © 2014 RED.COM, INC
RED DSMC OPERATION GUIDE
955-0020_V5.1, REV-H | 58
FORMAT MAX FRAME RATE (FPS) FORMAT MAX FRAME RATE (FPS)
4K WS 148.68 2K 2:1 239.67
4K HD 119.51 2K WS 295.68
4K 3:2 101.14 2K HD 237.94
4K 4:3 90.06 2K 3:2 201.50
4K 5:4 84.51 2K 4:3 179.51
4K 4:1 239.67 2K 5:4 168.47
4K 8:1 399.60 2K 4:1 399.60
3.5K FF 135.51 2K 8:1 399.60
SCARLET-X DRAGON FRAME RATES
The table below describes the maximum frame rate for each resolution of the SCARLET-X DRAGON camera.
The minimum frame rate is always 1 FPS.
NOTE: All frame rates in the table below are based on a 23.98 time base, 8:1 compression, and with Lookaround
disabled.
FORMAT MAX FRAME RATE (FPS)
6K FF 12.08 (in Burst mode)
5K FF 24.22
5K 2:1 25.52
5K 2.4:1 30.17
5K 16:9 25.81
4K FF 38.42
4K 2:1 38.69
4K 2.4:1 47.94
4K 16:9 40.96
3K FF 67.29
3K 2:1 70.91
3K 2.4:1 83.80
3K 16:9 71.70
2K FF 121.83
2K 2:1 128.50
2K 2.4:1 150
2K 16:9 121.83
