RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC
955-0020_V5.1, REV-H | 59
EPIC MYSTERIUM-X AND SCARLET MYSTERIUM-X FRAME RATES
The table below describes the maximum frame rate for each resolution of the EPIC MYSTERIUM-X and SCAR-
LET MYSTERIUM-X cameras.
The minimum frame rate is always 1 FPS.
The table below omits rows for the anamorphic formats, since the maximum frame rate for each anamorphic
format and the corresponding non-anamorphic format is the same.
NOTE: All frame rates in the table below are based on a 23.98 time base, 8:1 compression, and with Lookaround
disabled.
FORMAT MAX FRAME RATE (FPS)
EPIC MYSTERIUM-X
MAX FRAME RATE (FPS)
SCARLET MYSTERIUM-X
5K FF 95.83 12
5K 2:1 100.83 12
5K WS 120.83 12
5K HD 95.83 12
5K 1.22:1 95.83 12
4K FF 120.83 30
4K WS 152.47 36
4K HD 120.83 30
3K FF 159.88 48
3K WS 200.88 60
3K HD 159.88 48
2K FF 239.67 60
2K WS 301.79 75
2K HD 239.67 60
1K HD 356.58 90
1K WS 400 120
