RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC
955-0020_V5.1, REV-H | 61
EXPOSURE CONVERSIONS
As you adjust any of these three parameters, the camera automatically calculates the equivalent value in the
other units, but as a quick reference here are some common speeds and angles.
CONVERT SHUTTER SPEED TO SHUTTER ANGLE (FOR 24 FPS)
Equivalent Degrees = (Shutter Speed x Frame Rate x 360)
For example: (1/48 x 24 x 360) = (8640/48) = 180
SHUTTER DEGREES SHUTTER DEGREES
1/32 270 1/120 72
1/48 180 1/192 45
1/50 172.8 1/348 22.5
1/60 144 1/696 11
1/96 90 1/1000 8.6
CONVERT SHUTTER ANGLE TO SHUTTER SPEED (FOR 24 FPS)
Equivalent Shutter = 1/(Frame Rate x 360/Angle)
For example: 1/(24 x 360/180) = 1/(8640/180) = 1/48
DEGREES SHUTTER DEGREES SHUTTER
270 1/32 72 1/120
180 1/48 45 1/192
172.8 1/50 22.5 1/348
144 1/60 11 1/696
90 1/96 8.6 1/1000
