COPYRIGHT © 2014 RED.COM, INC
RED DSMC OPERATION GUIDE
955-0020_V5.1, REV-H | 74
trol), go to the BRAIN GPIO tab and set the Camera Input option to Sync In.
NOTE: When using MoCo, you must set the frame rate to be at least two times (2x) the fastest trigger
rate used. A high frame rate usually increases the compression, but when you’re using MoCo, RED-
CODE is calculated based on FPS/2. Therefore, if you are in MoCo mode, and you set the frame rate to
100.83 FPS, the maximum REDCODE is calculated based on a frame rate of 50.415 FPS.
Genlock Source: Select which genlock input should be used:
‒ BRAIN (default)
‒ Rear Module
BRAIN GPIO
Camera Input: Select one of the following options to configure the input for devices connected to the SYNC
connector on the BRAIN:
‒ Sync In: The camera input is used as a sync-in signal for MoCo.
‒ General Purpose In: Use the BRAIN GPI In High/Low drop-down menus to map inputs to actions.
Camera Output: Select one of the following options to configure the output for devices connected to the
CTRL connector on the BRAIN:
‒ Sync Out: Provides an output sync signal to act as a shutter start tally.
‒ Recording Indicator Out: Provides a signal when recording is in process.
NOTE: For more information about connectors, go to “Input/Output Connectors” on page 121.
GEN AND SYNC STATUS ICONS
The Lower Status Row of the camera display has GEN and SYNC icons, which change color based on the
current genlock and sync statuses. For information about what each color indicates, go to “Icon Behavior” on
page 40.
