BRAIN LEDS
This section describes the LED functions for the WEAPON BRAIN.
LED COLOR/FLASHING DESCRIPTION
Power Status LED
(PWR)
Off No power present
Green Power present; camera on
Amber flashing Power present; 5–10 min of battery time left
Amber Power present; camera booting
Red flashing Power present; < 5 min of battery time left
Red Power present; camera off
Record Status LED
(REC)
Off No media present
Green Ready to record
Amber Finalizing
Red flashing (slow) Recording; 25% media left
Red flashing (fast) Recording; 5% media left
Red Recording
Power Status LED (PWR)
and Record Status LED (REC)
Both green flashing Firmware update in progress
Both red flashing Firmware update error
