RED DSMC OPERATION GUIDE: WEAPON
COPYRIGHT © 2015 RED.COM, INC 955-0116_V6.1, REV-H | 21
DSMC
2
REDVOLT EXPANDER
Designed for advanced configurations, the DSMC
2
REDVOLT
®
Expander mounts directly to the BRAIN and
offers an expansive array of I/O connectors and functionality available for the WEAPON system. The DSMC
2
REDVOLT Expander features ports for power in (DC IN), Genlock (BNC), Timecode (LEMO), GIG-E, and more.
HDMI and two 3G-SDI (HD-SDI) outputs offer versatility for your video output needs, while an integrated USB
power output is available to support wireless HDMI transmitters.
The DSMC
2
REDVOLT Expander offers a modular audio system that you can remove and replace with upcoming
audio modules. The default audio module offers two (2) female XLR audio connections. Each XLR input features
a 3-position selector switch to designate the incoming audio signal type: Balanced Line Level, Balanced Mic
Level, and Balanced Mic with +48V phantom power. Additionally, a 3.5mm line-level headphone jack lets you
sample audio during takes and in playback mode.
The DSMC
2
REDVOLT Expander also provides multiple auxiliary power outputs, enabling the use of peripheral
camera accessories and more:
 A rear-facing 4-Pin 0B LEMO AUX PWR output supports Start/Stop Trigger IN, Tally OUT, and provides
power out up to 1.5 Amps.
 A front-facing 2-Pin 0B LEMO AUX PWR port and front-facing 7-Pin 0B LEMO SERIAL port share a total
output of 3.0 Amps. The SERIAL port is ideal for powering motor drivers.
 A rear-facing Timecode port offers 5V at 1.5 mA for powering external timecode devices.
 A rear-facing USB port offers 5V at 1.5 Amps for powering HDMI transmitters or small mobile devices.
 The two XLR audio ports in the default audio module each offer +48V phantom power.
For hot-swap support when it matters most, the DSMC
2
REDVOLT Expander also supports a single REDVOLT
battery. Additional WEAPON-compatible battery and power modules can be mounted for your changing power
needs.
The DSMC
2
REDVOLT Expander also features a selector switch that enables the BRAIN to automatically boot
when power is provided via the DC IN connector on the expander. This feature allows you to use a connected
DC input supply to turn the BRAIN on and off when the camera is mounted in remote or difficult to maneuver
locations. This expander is the ideal solution for a variety of production environments, maximizing camera
interface and functionality for the most demanding shoots.
NOTE: Only one (1) expander module can be used at a time.
DSMC
2
REDVOLT Expander
