COPYRIGHT © 2015 RED.COM, INC
RED DSMC OPERATION GUIDE: WEAPON
955-0116_V6.1, REV-H | 22
DSMC
2
JETPACK EXPANDER
The DSMC
2
Jetpack Expander is specifically designed for aerial, gimbal, handheld, and other lightweight/remote
configurations. This expander features standard connectors for power (DC-IN), CTRL, and SYNC for all of your
Timecode and Genlock needs. In addition, the DSMC
2
Jetpack Expander offers custom-tailored supports and
connectors for HDMI and USB power out—perfect for housings and low-profile setups.
The DSMC
2
Jetpack Expander also features a selector switch that enables the WEAPON BRAIN to automatically
boot when power is provided via the DC IN connector on the expander. This feature allows you to use a
connected DC input supply to turn the BRAIN on and off when the camera is mounted in remote or difficult to
maneuver locations.
NOTE: Only one (1) expander module can be used at a time.
DSMC
2
Jetpack Expander
