11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Cylinder Assembly
52
Section F
* Not Sold Separately, Only Available As A Seal Repair Kit
** See Complete Boom Breakdown for Pin Information
1 492675 492672 492675 Clevis Cap 1
2 492670 492665 492670 Rod Cap 1
3 494719 494765 494719 Piston 1
4 493582 493107 493272 Cylinder Rod 1
5 491740 491612 491742 Cylinder Tube 1
6 492280 492222 492282 Tie Rod 4
7 469528 ** ** Cylinder Pin 2
8 135995 ** ** Pin 4
9 498006 498006 498006 Thrd Lock-Nylon 1
10 492652 492650 492652 Rod Clevis 1
11 148390 148390 148390 SC SCKT Set 3/8 UNC 1
12 NUT-050 NUT-038 NUT-050 Nut, Hex (Tie Rod) 8
13 130560 130556 130560 Nut, Hex (Cly. Rod) 1
14 186562 186562 186562 Plug 3/4-16, Soc HD 1
9030-22 639542 9030-22 Seal Repair Kit
15* Seal 2
16* O-Ring 2
17* Seal Hallite 1
18* O-Ring 1
19* Seal NOK 1
20* Seal PTFE Piston Ring 1
21* Wear Ring 1
P/N 645215 20TD12-112 P/N 645216
Wing Tilt 60’ Boom 90’ Boom
Item# 180° Fold 180° Fold Description Quantity
