Redball 680 - Tire Weight Capacities

8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1600
14.0 lb/gal 750 1000 1350 1569
16.0 lb/gal 750 1000 1350 1373
Static Load Boom Height** Minimum 28”, Maximum 68” Spindle and Hub Assembly: 10-Bolt
Maximum Solution Tank Capacity in Gallons at 25 MPH with 14.9-46, 3 Star Size Tires, DUALS
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1426
14.0 lb/gal 750 1000 1222 1222
16.0 lb/gal 750 1000 1070 1070
Static Load Boom Height** Minimum 28”, Maximum 68” Spindle and Hub Assembly: 10-Bolt
Maximum Solution Tank Capacity in Gallons at 25 MPH with 14.9 - 46, 8 Star Size Tires
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1600
14.0 lb/gal 750 1000 1350 1422
16.0 lb/gal 750 1000 1245 1245
Static Load Boom Height ** Minimum 26”, Maximum 66” Spindle and Hub Assembly: 10-Bolt
Maximum Solution Tank Capacity in Gallons at 25 MPH with 270/95 x R48-22 Size Tires, DUALS
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
11-01
680 High Clearance Sprayer - Connection & Startup
Section C
3
Section C
Tire Weight Capacities - 25 MPH
Use this chart as a guide to determine the maximum amount of various solutions your
sprayer tires are rated for. 8 MPH is the service or field speed for this sprayer. 25 MPH is
used here to demonstrate a speed used to transport the sprayer, NOT as a service or field
speed. Only the operator can determine the maximum safe operating speed of the sprayer.
NOTE
Refer to the tire manufacturer recommendations to deter-
mine the correct tire pressure.
IMPORTANT
8.3 lb/gal (Water) 750 964 959 959
10.0 lb/gal 750 800 796 796
12.0 lb/gal 667 667 664 664
14.0 lb/gal 571 571 569 569
16.0 lb/gal 500 500 498 498
Static Load Boom Height** Minimum 22”, Maximum 60” Spindle and Hub Assembly: 8-Bolt
Maximum Solution Tank Capacity in Gallons at 25 MPH with 320/85 x R38 Size Tires
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
** Standard non-hooded booms measured approximately to bottom of boom frame.
