11-01
4
Section C
680 High Clearance Sprayer - Connection & Startup
Section C
Tire Weight Capacities - 8 MPH
Exceeding the weight capacity of the sprayer’s tires may
result in structural failure and will void the warranty.
IMPORT
ANT
Use this chart as a guide to determine the maximum amount
of various solutions your sprayer tires are rated for.
NOTE
8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1600
14.0 lb/gal 750 1000 1350 1600
16.0 lb/gal 750 1000 1350 1445
Static Load Boom Height ** Minimum 26”, Maximum 66” Spindle and Hub Assembly: 10-Bolt
8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1600
14.0 lb/gal 750 1000 1350 1600
16.0 lb/gal 750 1000 1350 1270
Static Load Boom Height** Minimum 28”, Maximum 68” Spindle and Hub Assembly: 10-Bolt
8.3 lb/gal (Water) 750 1000 1350 1600
10.0 lb/gal 750 1000 1350 1600
12.0 lb/gal 750 1000 1350 1600
14.0 lb/gal 750 1000 1350 1430
16.0 lb/gal 750 1000 1251 1251
Static Load Boom Height** Minimum 28”, Maximum 68” Spindle and Hub Assembly: 10-Bolt
Maximum Solution Tank Capacity in Gallons at 8 MPH with 14.9 - 46, 8 Star Size Tires
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
Maximum Solution Tank Capacity in Gallons at 8 MPH with 270/95 x R48-22 Size Tires, DUALS
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
Maximum Solution Tank Capacity in Gallons at 8 MPH with 14.9-46, 3 Star Size Tires, DUALS
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
Refer to the tire manufacturer recommendations to deter-
mine the correct tire pressure.
IMPORTANT
8.3 lb/gal (Water) 750 1000 1174 1174
10.0 lb/gal 750 976 974 979
12.0 lb/gal 754 813 812 812
14.0 lb/gal 697 697 696 696
16.0 lb/gal 610 610 609 609
Static Load Boom Height** Minimum 22” , Maximum 60” Spindle and Hub Assembly: 8-Bolt
Maximum Solution Tank Capacity in Gallons at 8 MPH with 320/85 x R38 Size Tires
Solution Weight Per Gallon 750 Gallon Tank 1000 Gallon Tank 1350 Gallon Tank 1600 Gallon Tank
