11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Cylinder Assembly; P/N K256
54
Section F
1 45288 Shaft; Weldment 1
2 40259 FND Gland 1
3* 20296 Seal Kit 1
4 91304 Tube Weldment 1
5 98261 Ppiston 1
6 96007 3/4-16UNF Locknut 1
7 56040 Danuser Threaded Eye 1
8 57300 1/4-20UNC SHSS 1
Item# Part # Description Quantity
* Not Sold Separately, Only Available As A Seal Repair Kit
** Not Shown
