680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Parallel Cylinder Assembly
56
Section F
1 8 Nut, Hex (Tie Rod) NUT-050 NUT-050
2 1 Nut, Hex (Cyl. Rod) 130556 130560
3 1 SC Sckt Set 3/8UNC 148390 148390
4 1 Plug 3/4-16, SOC HD 186562 186562
5 1 Cylinder Tube, Weld 464416 464418
6 4 Tie Rod 492282 492282
7 1 Rod Clevis 492650 492652
8 1 Clevis Cap 492660 492675
9 1 Rod Cap 492661 492670
10 1 Cylinder Rod 493272 493580
11 1 Piston 494727 494719
12 1 Thrd Lock-Nylon 498066 498006
Seal Repair Kit 639557 939558
13* 1 Seal PTFE Piston Ring
14* 1 Seal Halite
15* 2 Seal
16* 2 O-Ring
17* 1 O-Ring
18* 1 Seal Nok
19* 1 Wear Ring
Item# Quantity Description P/N 645213 P/N 645214
* Not Sold Separately, Only Available As A Seal Repair Kit
