11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
Description: 10-Bolt Fixed Axle Assembly (3/4” Stud)
64
Section F
1 006961* Axle; 10-Bolt Fixed 72” 1
006958* Axle; 10-Bolt Fixed 88”
006953* Axle; 10-Bolt Fixed 120”
2 BH-075-250-5 Bolt; 3/4 x 2 1/2 Gr. 58
3 LN-075-NI Locknut; 3/4 Nylon Insert 8
4 BH-050-500-5 Bolt, 1/2” x 5” Hex. Gr. 5 1
5 LN-050-NI Locknut, 1/2” Nylon Insert 1
6 913571 Wheel Nut 3/4” - 16 UNC Flanged 10
7 149R46** 14.9 x 46 Tire/Rim (Single) 1
320-90R46 Tire & Wheel; (12.6")
8 2813180L16 Spindle 680 10-Bolt 1
LS5545K-00 Spindle 680 10-Bolt (Duals Only)
9 2891300* Complete Hub Assembly 1
10 906497 Grease Seal 1
11 910333 Inner Cone 1
P752336 Inner Cone (Duals Only)
12 910331 Inner Cup 1
13 913564 Stud Bolt 3/4 - 16 UNC (Single Wheel) 10
953033 Stud Bolt 3/4 - 16 UNC (Dual Wheel)
14 Machine Casting 1
15 910334 Outer Cup 1
16 910332 Outer Cone 1
17 905944 Cotter Pin, Spindle 1
18 913632 Flat Washer, Spindle 1
19 912969 Nut, Spindle, 1 1/4” - 12 1
20 905205 Bolt, Dust Cap 4
21 909983 Dust Cap 1
22 270/95R48-22* 270/95 x R48 - 22” Tire/Rim (Dual) 1
149R46DU* 14.9 x 46 - 30” Tire/Rim (Dual)
Item# Part # Description Quantity
** Specify Color
Note - Specify whether is for left or right and if inner or outer for dual setup.
