Redball 680 - Liquid System

11-01
680 High Clearance Sprayer - Maintenance, Service &
Troubleshooting
Section E
SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION
Poor spray pattern Nozzles too large See Nozzle Supplier
- Nozzles Dribble
Strainer Clogged Clean Strainer
- Spray atomizing Nozzle too small See Nozzle Supplier
& blowing around
Tractor speed too fast Reduce speed
- Spray Streaming Nozzle partially clogged Remove and clean nozzles
(No uniform pattern) and strainer
- Won’t spray Controller not setup See Controller
Manufacturer’s Manual
Valves not in correct position See Section B
Poor hydraulics or Troubleshoot hydraulic
no hydraulic power system
Liquid supply blocked Clean strainer
Suction line collapsed Inspect and replace
Suction line blocked Remove obstruction
Liquid System
8
Section E
