680 High Clearance Sprayer - Parts & Schematics
Section F
1 004150* Hitch, Weld (750 Frame Only) 1
004870* HItch, Weld (1350 All., 1000/40-60’)
006025* Hitch, Weld (1600 Frame Only)
006037* Hitch, Weld (1000 Frame/90’ Only)
2 004582* Drawbar, 2-Pt. Weld
(all 750’s & 1000-90’ Boom) 1
004880* Drawbar, 2-Pt. Weld
(1000-60’ & all1350 & 1600’s)
3a PPI-331VH Hitch, Pintle 1
3b PPI-208VR Pintle, Clevis
3c VB85 Bolt, Clevis
3d VB91 Nut, Clevis
4 004110* Pigtail, Weld 1
5 004570* 2-Pt. Hitch, Weld 1
6 004576* 2-Pt. Jackstand, Weld 2
7 004752 Jackstand Weld 1
8 004753 Pin, Cotterless, 1/2” x 3 1/2” 1
9 006933 Chains, Safety 2
10 34H334 Roll Pin, 5/16” x 2” 2
11 AR62149 Quick Lock Pin, 3-Pt. Hitch 2
12 BH-025-250-2 Bolt, 1/4 x 2 1/2” Hex. Gr. 2 1
13 BH-062-350-5 Bolt, 5/8” x 3 1/2” Hex. Gr. 5 2
14 BH-075-250-5 Bolt, 3/4” x 2 1/2” Gr. 5 12
15 BH-100-650-5 Bolt, 1” x 6 1/2” Gr. 5 2
16 LN-025-NI Locknut, 1/4” Nylon Insert 1
17 LN-062-NI Locknut, 5/8” Nylon Insert 2
18 LN-075-NI Locknut, 3/4” Nylon Insert 12
19 LN-100-NI Locknut, 1” Nylon Insert 2
20 N130465 Spacer, 3-Pt. Hitch, Bottom 2
21 N233354 Bushing, 3-Pt. Hitch Bottom 2
22 N281027* Pivot, 2-Pt. 1
23 N281739 Pin, 15 3/4” x 1 1/2” 1
24 N281745 Pin, 9” x 1 1/2” 1
25 N61495 Pin, 3-Pt. Hitch, 9” x 1 1/8” 2
26 PCL-050-350 Pin, 1/2” x 3 1/2” Clevis Pin-Zinc 2
27 HPC-210 Pin Clip, 2 3/16” x 7/8” Leg Stand 2
28 007679* Pigtail Weld 2
29 LN-031-NI Locknut; 5/16 Nylon Insert 2
30 BH-031-100-5 Bolt; 5/16 x 1 Hex Bolt 2
Item# Part # Description Quantity
Description: Drawbar Assembly
*Specify Color Where Applicable
8
