680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Sight Gauge and Tank Support Assembly
1 NW60401 Bulkhead Fitting 3/4” 1
2 HB-075-90 Hose Barb El, 3/4 MPT x HB Poly 1
3 #12J Clamp, 3/4” Stainless Clamp 5
4 SIGHT-34 Hose, 3/4” Clear Sight Hose
5 EL34HB Hose Fitting, 3/4 ELHB x 3/4 HB 1
6 001212 Hose, 3/4” 150# EPDM, L85
7 M100BRB Hose Barb, 1” Flanged Straight 1
8 FC100BJ Clamp, 1” 1
9 100G Gasket; 1” Coupling EPDM 1
10 M100MPT Manifold; 1” x 1” Male Thread 1
11 NW60427 Bulkhead Fitting 1” 1
12 BH-025-100-S Bolt; 1/4” x 1” Hex. Stainless 2
13 LN-025-NI-S Lock Nut; 1/4” Nylon Insert Stainless 2
14 007666 Sleeve, Tank Spreader Weld 1
15 007667 Shaft, 1350 Tank Spreader 1
007668 Shaft, 1600 Tank Spreader
Item# Part # Description Quantity
