11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
14
Section F
7 19349-211-785NY Hose Shank 3/4 HB, EL Diaph
QJ363-750-1-NYB Turret, 3 - Outlet, 3/4 Tee
QJ365-750-1-NYB Nozzle Body Mult, W/L Hose S
8 LN-031-NI Lock Nut, 5/16” Nylon Insert
9 004528 Pin, Weld 20 7/8” Lg.1
10 004532 Pin, Weld 10 7/8” Lg.1
11 5523 Spring, Extension 1 1/4 O.D. 1
12 660128 Shock Absorber
13 BE-050-600 Bolt, Eye 1/2 x 6
14 BH-050-275-5 Bolt, 1/2 x 2 3/4 Gr. 52
15 BH-025-250-5 Bolt, 1/4 x 2 1/2 Gr. 55
16 LN-025-NI Locknut 1/4” Nylon Insert 5
17 LN-050-NI Locknut 1/2” Nylon Insert 3
18 PCT-012-150 Pin, Cotter 1/8 x 1 1/2 1
19 MB-075-10 Bushing, Machine 3/4 PL. 10 GA 1
20 004530 Pin, Weld 4 1/2”
21 001459 Spring Hook Weld HBS-303 1
22 BH-100-650-5 Bolt, 1 x 6 1/2 Gr. 5
23 004540 Pin, Weld 6” Lg.
24 004644 Pin, Weld 7” Lg.
25 004646 Bushing, 2 7/8” Lg.
26 004647 Bushing, 3 7/8” Lg.
27 004548 Mount, Wing Fold
28 006315 Wldmt, Spacer Mount1
29 001506 Pad, Bumper
30 171-C #8 x 3/4” Self Tapping Screw 4
31 001212 Hose; 3/4" 150# EPDM
32 #12J Clamp; 3/4" x 1/2" Stainless
33 004124 Weld; Wing Rest; (Open Boom)
004630 Weld; Wing Rest (Hooded Boom)
34* 006304 Weldment; Cradle (R.S) Used on 100'
007552 Weldment; Cradle (R.S) Used on 80', 88', 90'
35 006302 Weldment; Cradle (L.S.) Used on 100'
007553 Weldment; Cradle (L.S.) Used on 80', 88', 90'
36 BU031-125-300 U-Bolt, 5/16 x 1 1/4 x 3 Sq.
Item# Part # Description Quantity
Description: Complete Boom Break Down
Quantity Listed are per side.
* NOT SHOWN
