680 High Clearance Sprayer - Parts & Schematics
Section F
1 001662 Slide, Nylitron Wear 14
001717 Spring, Compression
93240 Spring, Compression (used on 100’)
3 004385 Mount, Center Weld 1
4 004404 Rod, Threaded End 1
5 004410 Center, Boom Weld 1
6 004424 Center Removable 1
7 004465 Wing, Pivot Weld 2
8 004470 Upper Link, Weld 2
9 004522 Pin, Weld 6 3/8” Lg. 2
10 004524 Pin, Weld 8 3/8” Lg. 2
11 004540 Pin, Weld 6” Lg. 2
12 004538 Pin, Weld 7 1/4” 2
13 004546 Nylitron Mount/Clamp 6
14 004549 Swing Arm 4
15 BF-031-150 Bolt, Elevator, 5/16 x 1 1/2” Elevator 28
16 BH-025-200-5 Bolt, 1/4 x 2 x Hex Gr. 5 2
17 BH-025-250-5 Bolt, 1/4” x 2 1/2” Hex. Gr. 5 6
18 BH-050-200-8 Bolt, 1/2” x 2” Hex. Gr. 8 12
19 BH-100-600-8 Bolt, 1” x 6” Hex. Gr. 8 4
20 BH-100-1000-8 Bolt, 1” x 10” Hex. Gr. 8 4
21 BU-031-200-275 U-Bolt, 5/16 x 2 x 2 3/4” Sq 7
22 FW-050 Flatwasher, 1/2” 40
23 FW-100 Flatwasher, 1” 4
24 LN-025-NI Locknut, 1/4” Nylon Insert 10
25 LN-031-NI Locknut, 5/16” Nylon Insert 14
26 LN-100-NI Locknut, 1” Nylon Insert 8
27 LN-050-CL Locknut, 1/2” Center Lock 12
28 NTF-031 Nut, 5/16” Flange Nut 28
29 NUT-100-J Nut, 1” Jam Nut 8
30 004092 Bracket, SMV Angle Bracket 1
31 JD5403 SMV, Slow Moving Sign, Galvan 1
33 BH-025-075-2 Bolt, 1/4” x 3/4” Hex. Gr. 2 2
Item# Part # Description Quantity
Description: Complete Center Section Break Down
