680 High Clearance Sprayer - Parts & Schematics
Section F
Description: Cradle Assembly
18
Section F
1 PCT-012-150 Pin, Cotter 1/8 x 1 1/2 2
2 LN-038-NI Locknut, 3/8” Nylon Insert 8
3 LN-050-NI Locknut, 1/2” Nylon Insert 4
4 004800 Weld, Cradle Pin 2
5 006041** Weld, Cradle Arm2
006298** Weld, Cradle Arm (750 Only
6 006063** Weld, Rest Catch2
7 006193 Plastic, Scrap (Yellow) 2
006194 Plastic, Scrap (Grey)
8 006195 Plastic, Scrap (Yellow) 2
006196 Plastic, Scrap (Grey)
9 171-C #8 x 3/4” Self Tapping Screw 8
10 MB-100-10 Bushing, Machine 1” x 10 Ga. 2
11 BU031-200-275-2 U-Bolt, 5/16 x 2 x 2 3/4 Gr. 2 Sq. 8
12 BH-038-125-2 Bolt, 3/8 x 1 1/4 Hex. Gr. 2 8
13 BH-050-100-2 Bolt, 1/2 x 1 Hex. Gr. 2 4
14 HPC208 Pin Clip, 3/16, Lockarms 2
Item# Part # Description Quantity
Notes:
Items 2 & 3 not used with 60’ and 66’ Boom
*Not Shown
**Specify Color
