Redball 680 - Page 77

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
9 150G Gasket, 2” Flanged Valves
10 30035 Connector, Terminal 18 Ga. Male
11 38045 Connector, Body Shroud 3 Pin
12 39000 Cable Seal, Green
13 4030-0016 Hose Barb, 1/4 FB3 1
14 4030-0017 Hose Barb, 1/8/B3 1
15 4030-0018 Tubing, 3/16 x .124 ID Yellow
16A+@ 063-0159-571 Meter RFM 55 Flow 1
16B+@ 063-0172-125 Valve Assembly 1” Poly M81 1
16C+ 063-0171-220 Console SCS 450 w/Serial Interface 1
16D@ 063-0159-531 Console AST 3 BM SCS 440 1
16E+@ 115-0159-492 Cable 10’ Console 1
16F+@ 006367 Cable Assembly 12’ Valve 1
17 ASG1604-REDBALL Gauge, 4”, 160 PSI, Ammonia 1
18 BH-025-075-2 Bolt, 1/4” x 3/4” Hex. Gr. 2 6
19 BH-038-300-2 Bolt, 3/8” x 3” Hex. Gr. 2 4
20 FC100BJ Clamp, 1” for Flanged Valves
21 FC200BJ Clamp, 2” for Flanged Valves
22* 106-0159-437 Mounting Bracket, Console 1
23 M200/125BRB90 Hose Barb, 2” x 1 1/4HB Elbow 1
24 LN-025-NI Locknut, 1/4” Nylon Insert 6
25 LN-038-NI Locknut, 3/8” Nylon Insert 4
26 M100BRB Hose Barb, 1” Flanged Straight
27 M100G Gasket, 1” Flanged Valves
28* M100PLG Plug, 1” w/1/8” Gauge Port 1
30 M200/125BRB Hose Barb, 2” x 1 1/4” Straight 2
31 M200PLUG025 Plug, Flange 2” w/1/4” Port 1
32 RED1299A Manifold Valve, 450 Special
33 RB1418-SS Reducer Bushing, 1/4 MPT x 1/8 1
34 UB200 U-Bolt for Banjo Ball Valves 2
35* 115-0159-493 Cable, 12 Ft Flow Extension (Option) 1
Item# Part # Description Quantity
Description: Raven
®
Controller, TeeJet
®
Valves (Optional)
26
Section F
* Not Shown
+ Available as Kit P/N 007310
