Redball 680 - Page 82

11-01
680 High Clearance Sprayer - Parts & Schematics
Section F
35 NW60401 Bulkhead Fitting 3/4” 2
36 NW60427 Bulkhead Fitting 1” 3
37 RB100-075 Reducer Bushing, 1 x 3/4 Poly 2
38 RN100-075 Reducer Nipple, 1MPT x 3/4MPT 2
39 TEE 100 Tee, Poly, 1” Female 1
40 V-075 Valve, 3/4” Bolted Ball Valve 1
41 V-200 Valve, 2” Bolted Ball Valve 1
42 V-204FP Valve, 2” 4 Bolted Ball Valve 1
43 VSF-200 Valve, Stub, 2”M ADPT x 2”F NPT 1
44 M220MPT 2” Manifold x 2” Full Port 1
45 006069 Mount, Flanged Strainer 1
46 M220BRB 2” Full Port Flange x 2” Hose Barb 1
47 MV220CF Valve, 2” Flange Valve FP 1
48 M220TEE 2” Full Port Tee 1
49 200G Gasket, 2” Full Port Flanged 4
50 FC220 Clamp, 2” Full Port 4
51 M200TEE 2” Flanged Tee 2
52 M200MPT 2” Manifold x 2” Flanged 1
53 NW60405 Bulkhead Fitting 2” 1
54 M100MPT 1” Manifold x 1” Flanged 2
55 M200CPG 2” Flange x 2” Flange 1
56 NW60401 Bulkhead Fitting; 3/4" 1
57 PLUG 075 Plug; 3/4" MPT, Poly 1
Item# Part # Description Quantity
Description: 680 Centrifugal Plumbing w/Flanged Fittings
31
Section F
