11-01
Description: Hydraulically Driven Centrifugal Pump Assembly
680 High Clearance Sprayer - Parts & Schematics
Section F
1 004656 Hyd. Hose, 180” 8FJX x 8 MB 2 2 2 2 2
2 006213 Mount, Pump Frame 1 1 1 1 1
3 150G Gasket, For 2” Flanged Valve 4 4 4 4 3
200G Gasket, For 2" FP Flanged Valve 1
4 6801-8 Hyd. Fitting, 1/2JICX x 1/2MPT 1 1 1 1 1
5 2501-8-8 Hyd. Fitting, 3/4MOx1/2JIC EL 1 1 1 1 1
6 8010-15P Hyd. Quick Coupler, Univ. Poppet 2 2 2 2 2
7 9303C-HM4 Pump, Hyd. Motor Cast 1
9303C-HM1 Pump, Hyd. Motor, Open Cent 1
9304C-HM1 Pump, Hyd. 190GPM Open/Close 1
9306C-HM1C Pump, Hyd. Cast 1In 1 1/2Out 1 1
7A 3430-0178 Repair Kit, 9300 Hydraulic Motor
7B 3430-0332 Seal Repair Kit (Viton), Pump
8 BH-038-150-2 Bolt, 3/8” x 1 1/2” Gr. 2 6 6 4 4
BH-038-125-2 Bolt, 3/8” x 1 1/4” Gr. 2 6
BH-038-250-2 Bolt, 3/8" x 2 1/2" Gr. 2 2 2
9 FC200BJ Clamp, 2” Flanged Valve 4 4 4 4 3
FC220 Clamp, 2" FP Flanged Valve 1
10 LN-038-NI Locknut, 3/8’ Nylon Insert 6 6 6 6 6
11 M200/100BRB Hose Barb, 2” x 1” Straight 1 1 1 1 1
12 M200/125BRB90 Hose Barb, 2” x 1 1/4” Elbow 90° 1 1 1 1 1
13 M200125MPT Manifold, 2” x 1 1/4” Male Thread 1 1
M200150MPT Manifold, 2” x 1 1/2” Male Thread 1 1 1
14 M200150MPT Manifold, 2” x 1 1/2” Male Thread 1 1
M200MPT Manifold 2” x 2” Male Thread 1 1
M220MPT Manifold 2” Full Port Thread 1
15 M200TEE Tee, Flanged 2” Manifold Fitting 1 1 1 1 1
16 #4 J Clamp, #4 J Stainless 2 2 2 2 2
17 K3150-025 Hose 1/4”, Clear Site 1/16 Wall
18 HB-025-90 Hose Barb Ell., 1/4MPT x 1/4HB 90° 1 1 1 1 1
19 A1814 Hose Fitting, 1/8” MPT x 1/4” HB 1 1 1 1 1
20 010263 Plate; Pump Spacer 2 2
Item# Part # Description 9303C-HM4 9303C-HM1 9304C-HM1 9306C-HM1C 9306C-HM1C
34
Section F
