Exhaust gas recirculation rigid pipe: Removal - Refitting
K9K, and 836
14A
a Disconnect the oil vapour rebreathing pipe from the
rocker cover (5) .
a Remove:
-the turbocharger air inlet pipe bolts (6) from the tur-
bocharger,
-the turbocharger air inlet pipe.
a Remove:
- the bolt (7) of the intermediate air pipe between the
turbocharger and the intercooler,
- the nut (8) for the intermediate air pipe between the
turbocharger and the intercooler,
- the clip (9) of the intermediate air pipe between the
turbocharger and the intercooler.
a Remove the intermediate air pipe between the tur-
bocharger and the intercooler.
a Remove:
- the clip (10) of the turbocharger air outlet pipe,
