Renault F9Q - Pinking Sensor: Removal - Refitting

17B-9
PETROL INJECTION
Pinking sensor: Removal - Refitting
K4M
17B
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the front engine cover.
a Remove:
- the dipstick,
- the bolts (1) from the dipstick tube,
- the dipstick guide.
a Remove:
- the alternator strut bolt (2) from the alternator,
- the alternator strut nut (3) from the cylinder block,
Essential special tooling
Emb. 1797 24 mm socket for removing
and refitting clutch master
cylinder
Tightening torquesm
pinking sensor 20 N.m
alternator strut bolt on
the alternator
25 N.m
alternator strut nut on
the cylinder block
25 N.m
alternator strut bolt on
the alternator
25 N.m
alternator strut bolt on
the cylinder block
25 N.m
dipstick guide tube bolts 10 N.m
K4M, and 858 or 866
136574
K4M, and 848
135727
