Renault F9Q - Ignition; Coils Removal - Refitting

17A-1
IGNITION
Coils Removal - Refitting
F4R
17A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove the front engine cover.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the coil connectors (1) .
a Disconnect the connector (2) from the camshaft de-
phaser solenoid valve.
a Remove the coil bolts (3) .
a Move aside the camshaft dephaser solenoid valve.
a Remove the coils.
Tightening torquesm
coil bolts 12 N.m
134238
135750
136528
