RZ/A2M SUB Board RTK79210XXB00000BE 1. Overview
R20UT4398EJ0100 Rev.1.00 1-2
2018.10.11
1.2 Configuration
Figure 1.1 shows an example of system configuration using RTK79210XXB00000BE.
Figure 1.1 RTK79210XXB00000BE System Configuration Example
NAND
U32
ON
1 2 3 4 5 6 7 8 9 10
LVDS
CN14
Backlight
CN16
LANUSB
mic
headphones
USB serial SD card
VDC6
CMOS camera
DRP
RZ/A2M CPU board
RTK7921053C00000BE *
RZ/A2M
RZ/A2M SUB board
RTK79210XXB00000BE
USB power supply (Mini-B only)
Max.500mA
ICE
Debugger
Host computer
*
DC 5V output
AC adapter
*
Mini-B
Type-A
*: Users need to prepare these separately.
Mounted on the reverse side of the board.
*
