2. Functional Specifications
2.1 Overview of Functions
Table 2.1.1 lists function modules of RTK79210XXB00000BE.
Table 2.1.1 Function Modules of RTK79210XXB00000BE
Section
Function
Description
2.2
CPU
• RZ/A2M pin functions used in the RTK79210XXB00000BE.
2.3
Memory
• SDRAM: 64 Mbytes x 1
- ISSI S42S16320F-7TL
• EEPROM: 16 KBytes x 1
- Renesas R1EX24128ASAS0A
• NAND flash memory: 128 MBytes x 1 is possible to mount on the board
pattern.
- Cypress S34ML01G100TFI000
2.4
USB interface
Connection for the RZ/A2M USB2.0 host/function module and USB connector
2.5
Serial interface
Connection for the RZ/A2M FIFO internal serial communication interface
(SCIFA) and RL78-intermediate USB Micro-B connector
2.6
Interrupt switch
Connection for the RZ/A2M NMI pin, IRQ0 pin, and push switch
2.7
Clock configuration
System clock configuration
2.8
Reset control
Reset control for the RZ/A2M CPU board and devices installed on the
RTK79210XXB00000BE
2.9
Power voltage configuration
System power supply configuration for the RZ/A2M CPU board and RTK79210XXB00000BE
2.10
Audio interface
Connection for the RZ/A2M Audio CODEC (WM8978)
2.11
CMOS camera interface
Connection for the RZ/A2M Capture engine unit (CEU) and the CMOS camera
connector
2.12
SD card interface
Connection for the RZ/A2M SD host interface (SDHI) channel 1 and SD card slot
2.13
LAN interface
Connection for the RZ/A2M Ethernet controller (ETHERC) and LAN connector
via Ethernet PHY
2.14
Key input switch
Connection for the RZ/A2M A/D converter (ADC) and push switches
2.15
VDC6 interface
Connection for the RZ/A2M Video display controller 6 (VDC6) and digital image
input/output connector
2.16
LVDS interface
Connection for the RZ/A2M LVDS interface and LVDS connector
2.17
DRP interface
Connection for the RZ/A2M DRP interface and DRP connector
―
Operation specifications
Refer to Chapter 3 for details on connectors and interfaces
