Renesas RZ/A Series User Manual

RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-7
2018.10.11
3.1.2 DRP Connector (CN2)
RTK79210XXB00000BE is equipped with a DRP connector (CN2).
Figure 3.1.4 shows the DRP connector pin layout diagram, and Table 3.1.4 shows the DRP connector pin layout table.
Figure 3.1.4 DRP Connector (CN2) Pin Layout Diagram
1 2
39 40
C side top view
CN2
