RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-8
2018.10.11
Table 3.1.4 DRP Connector (CN2) Pin Layout Table
Pin
Signal name
Pin
Signal name
1
P6_4 / AUDIO_CLK / DRP00
2
P6_5 / CS3 / DRP01
3
P6_6 / DRP02
4
P6_7 / WE0/DQML / DRP03
5
Vss
6
P7_0 / WE1/DQMU / DRP04 / SCK1
7
P7_1 / RD/WR / DRP05 / RxD1
8
P7_3 / RAS / DRP06 / TxD1
9
P7_4 / CAS / DRP07 / RTS1
10
Vss
11
P7_5 / CKE / DRP08 / CTS1 / OVRCUR1
12
P9_7 / A15 / DRP09
13
P9_6 / A14 / DRP10 / SSIBCK0
14
P9_5 / A13 / DRP11 / SSIFS0
15
+3.3V
16
P9_4 / A12 / DRP12 / SSITxD0
17
P9_3 / A11 / DRP13 / SSIRxD0
18
P9_2 / A10 / DRP14
19
P9_1 / A9 / DRP15 / RxD4
20
+3.3V
21
P9_0 / A8 / DRP16 / TxD4
22
P8_7 / A7 / DRP17 / RSPCK0
23
P8_6 / A6 / DRP18 / MOSI0
24
P8_5 / A5 / DRP19 / MISO0
25
+5V
26
P8_4 / A4 / DRP20 / SSL00
27
P8_3 / A3 / DRP21
28
P8_2 / A2 / DRP22
29
P8_1 / A1 / DRP23
30
+5V
31
P0_0 / D0 / DRP24
32
P0_1 / D1 / DRP25
33
P0_2 / D2 / DRP26
34
P0_3 / D3 / DRP27
35
Vss
36
P0_4 / D4 / DRP28
37
P0_5 / D5 / DRP29
38
P0_6 / D6 / DRP30
39
P1_0 / D7 / DRP31
40
Vss
[Note] Red characters indicate functions in use.
