RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-6
2018.10.11
Table 3.1.3 CPU Board Connector (CN1) Pin Layout Table (3)
Pin
Signal name
Pin
Signal name
157
Vss
158
Vss
159
PJ_1 / IRQ0
160
P1_0 / D7 / DRP31
161
PH_5 / NAF2 / ET1_EXOUT
162
Vss
163
PH_6 / ET1_WOL
164
PK_4 / ET1_RXD0/RMII1_RXD0 / NAF7
165
Vss
166
P3_1 / ET1_RXER/RMII1_RXER / FALE
167
PK_5 / NAF1
168
Vss
169
PG_4 / VIO_D15
170
P4_0 / TXOUT0P
171
PG_6 / VIO_D13
172
P4_1 / TXOUT0M
173
P1_4 / D11
174
Vss
175
Vss
176
P4_4 / TXOUT2P
177
P3_3 / ET1_MDC / FWE
178
P4_5 / TXOUT2M
179
P1_1 / D8
180
Vss
181
PG_7 / VIO_D12
182
P4_2 / TXOUT1P
183
PG_5 / VIO_D14
184
P4_3 / TXOUT1M
185
Vss
186
Vss
187
P3_4 / ET1_MDIO / FRB
188
P4_6 / TXCLKOUTP
189
P1_3 / D10
190
P4_7 / TXCLKOUTM
191
P3_0 / ET1_LINKSTA
192
Vss
193
P2_1 / D13
194
PC_0 / VBUSIN1
195
Vss
196
P1_2 / D9
197
PC_1
198
P2_2 / D14
199
P2_3 / D15
200
P2_0 / D12
201
Vss
202
PC_2
203
NMI
204
Vss
[Note] : 5V power source, : 3.3V power source, : GND
