RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-4
2018.10.11
Table 3.1.1 CPU Board Connector (CN1) Pin Layout Table (1)
Pin
Signal name
Pin
Signal name
1
D5V
2
D5V
3
D5V
4
D5V
5
D5V
6
D5V
7
RES#
8
PC_5 / VBUSEN1
9
D3.3V
10
PC_3 / LCD0_TCON4
11
D3.3V
12
AVcc
13
D3.3V
14
P5_6 / AN006
15
P5_3
16
AVss
17
P5_5 / SD1_WP
18
P5_4 / SD1_CD
19
P5_7 / IRQ3
20
PC_4 / LCD0_TCON3
21
D3.3V
22
Vss
23
P6_7 / WE0/DQML / DRP03
24
SD1_CLK
25
P7_0 / WE1/DQMU / DRP04 / SCK1
26
Vss
27
D3.3V
28
SD1_CMD
29
SD1_DAT1
30
Vss
31
SD1_DAT2
32
SD1_DAT3
33
SD1_DAT0
34
Vss
35
Vss
36
P6_4 / DRP00 / AUDIO_CLK
37
P7_2 / DV0_CLK
38
Vss
39
Vss
40
PB_4 / DV0_DATA1 / LCD0_DATA22
41
P7_3 / RAS / DRP06 / TxD1
42
P9_3 / A11 / DRP13 / SSIRxD0
43
PG_2 / VIO_D10
44
P7_7 / DV0_HSYNC / LCD0_TCON0
45
P7_5 / CKE / DRP08 / CTS1 / OVRCUR1
46
Vss
47
Vss
48
PL_1 / MD_CLK / IRQ5
49
P9_6 / A14 / DRP10 / SSIBCK0
50
PL_0 / MD_CLKS / IRQ4
51
Vss
52
Vss
53
P7_6 / DV0_VSYNC / GTIOC3A
54
CKIO
55
P9_5 / A13 / DRP11 / SSIFS0
56
Vss
57
PB_5 / DV0_DATA0 / LCD0_DATA23
58
PD_7 / RIIC3SDA
59
P9_2 / A10 / DRP14
60
PD_6 / RIIC3SCL
61
PB_3 / DV0_DATA2 / LCD0_DATA21
62
Vss
63
PB_1 / DV0_DATA4 / LCD0_DATA19
64
PB_0 / DV0_DATA5 / LCD0_DATA18
65
Vss
66
PB_2 / DV0_DATA3 / LCD0_DATA20
67
PA_6 / DV0_DATA7 / LCD0_DATA16
68
PA_3 / DV0_DATA10 / LCD0_DATA13
69
PA_4 / DV0_DATA9 / LCD0_DATA14
70
Vss
71
PA_5 / DV0_DATA8 / LCD0_DATA15
72
PG_0 / VIO_D8
[Note] : 5V power source, : 3.3V power source, : GND
