3-7
www.renishaw.com/lp2
Lathes (optical transmission)
CNC machine
controller
Stylus
LP2
probe
Workpiece
Typical
optical
module
Cable
Mounting bracket
OSI or OSI-D
interface unit
Cable
OMI-2/OMI-2T/OMI-2H
OMM-2
