Renishaw LP2 Installation Guide

6-1
www.renishaw.com/lp2
Parts list
Item Part number Description
LP2 A-2063-6098
LP2 probe complete with two C spanners and TK1 tools.
LP2H A-2064-0002 LP2H probe complete with two C spanners and TK1 tools.
MA2 probe holder A-2063-7868 MA2 probe holder, complete with holding screws.
Adaptor M-2063-7865 Shank adaptor for MA2 probe holder, complete with holding
screws.
Cable A-1016-6451 Cable assembly for MA2 probe holder.
Service kit A-2063-7542 LP2 service kit comprises: front cover, eyelid seal, spring and
O-rings.
LP2DD A-2063-8020 LP2DD probe complete with two C spanners and probe head
tools.
LP2HDD A-2064-0032 LP2HDD probe complete with two C spanners and probe head
tools.
Deector M-2063-8003 Swarf deector, Ø28mm, protects probe from hot swarf.
Diaphragm kit A-2063-8030
Outer diaphragm and O ring replacement kit.
Conversion kit A-2063-8023 The kit converts LP2 and LP2H probes to the DD standard,
comprising: front ring, outer diaphragm, O ring, two C spanners.
PS3-1C A-5000-3709 Ceramic stylus 50mm long with Ø6mm ball.
PS2-41 A-5000-6403
Square tool setting stylus.
Protection M-5000-7582 Stylus adaptor with weak link collision protection for straight steel
styli.
Protection M-5000-7587 Screw with weak link collision protection for straight steel styli.
Protection M-5000-7588 Screw with weak link collision protection for swivel adaptor.
TK1 A-2053-7531 Probe head tool kit.
C spanner A-2063-7587 C spanner.
MI 8-4 interface A-2157-0001 MI 8-4 interface unit with dual lock pads and DIN rail mounting,
installation and user’s guide and packaging.
HSI interface A-5500-1000 HSI probe system interface with DIN rail mounting and three
terminal blocks, quick-start guide and packaging.
HSI-C interface A-6527-1000 HSI-C probe system interface, quick-start guide and packaging.
Terminal block
(HSI-C only)
P-CN47-0082 4-way terminal block (1 off required).
Terminal block
(HSI-C only)
P-CN47-0083 5-way terminal block (5 off required).
Terminal label set
(HSI-C only)
M-5358-0202 HSI-C terminal labels.
Publications. These can be downloaded from our website at www.renishaw.com.
MI 8-4 H-2000-5008 Installation guide: for set-up of the MI 8-4 interface unit.
HSI H-5500-8554 Installation guide: for set-up of the HSI interface unit.
HSI-C H-6527-8501 Installation guide: for set-up of the HSI-C interface unit.
ACS-1 H-6974-8501 Installation guide: for set-up of the ACS-1.
