Renishaw PH10 Series User Manual

13
System description
2.3 Features
All the heads in the range incorporate the following features:
• 720indexingpositions
• 0.4µmindexingrepeatability*
• 7.5°indexingstepsinbothaxes
• 300mm(maximum)extensionbarcapability*
* Seesection2.7forspecicationsandtestconditions.
2.4 PH10T
Figure 1 shows the PH10T motorised probe head fitted with a TP200 probe.
Figure 1 - PH10T
B axis
A axis
